South Galaxy G1













Hubungi Kami



Spesifikasi GPS Geodetik South G1 :


Channel 220 Channels
Signal Tracking
BDS B1, B2, B3,
GPS L1C/A, L1C, L2C, L2E, L5
GLONASS L1C/A, L1P, L2C/A,L2P, L3
SBAS  L1C/A, L5( Just for the satellites supporting L5 )
Galileo GIOVE-A, GIOVE-B, E1, E5A, E5B
QZSS,WAAS, MSAS, EGNOS, GAGAN, SBAS

GNSS Feature
Positioning output rate: 1HZ~50HZ
Initialization time :  <10s
Initialization reliability : >99.99%
Positioning Precision
Code Differential GNSS Positioning

Horizontal:                                 0.25 m + 1 ppm
Vertical:                                     0.50 m + 1 ppm
SBAS positioning accuracy:     typically<5m 3DRMS
Static GNSS Surveying
Horizontal:                                 2.5 mm + 0.5 ppm
Vertical:                                     5 mm + 0.5 ppm
Real-Time Kinematic Surveying (Baseline<30km)
Horizontal:                                 8 mm + 1 ppm
Vertical:                                     15 mm + 1 ppm
Horizontal:                                 8 mm + 0.5 ppm
Vertical:                                     15 mm + 0.5 ppm

Network RTK
RTK initialization time:               2~8s
Physical
Dimension:  12.9cm × 11.2cm
Weight : 970g(includiing installed battery)
Communications and Data storage
I/O Port
5PIN LEOM external power port + RS232
7PIN LEOM RS232 + USB
1 network/radio data link antenna port
SIM card slot
Wireless Modem
Integrated internal radio receiver and transmitter 0.5W/2W
External radio transmitter 5W/25W
Working frequency
410-470MHz
Communication protocol
TrimTalk450s, TrimMark3, PCC EOT, SOUTH
Cellular Mobile Network
WCDMA3.5G network communication module, GPRS/EDGE compatible, CDMA2000/EVDO
3G optional
Double Module Bluetooth
BLEBluetooth 4.0 standard, support for android, ios cellphoon connection
Bluetooth + EDR standard
NFC communication
Realizing close range ( shorter than 10cm ) automatic pair between Galxy G1 and controller
(controller equipped NFC wireless communication module needed)
Data storage/Transmission
4GB internal storage, more than 3 year raw observation data (1.4M/day) base on recording from 14 satelites Plug and play more of USB data transmission
Data Format
Differential data format: CMR+, CMRx, RTCM2.1, RTCM2.3, RTCM3.0, RTCM3.1, RTCM3.2
GPS output data format:   NMEA0813, PJK plan, cordinates binary code
Network model support:   various, FKP, MAC, supporting NTRIP protocol
Intertial Sensing System
Tilt survey
Built-in tilt compensator, correcting coordinates automaticlly according to the tilt direction and angle of the centering rod

Electornic Bubble
Conteroller software display electronic bubble, checking leveling status of the centering rod real time



Titan TR7




Hubungi Kami




Spesifikasi GPS GEODETIC TITAN TR7 :

Size:137mm x 131mm
Weight:1.35kg including battery
Power:6 – 28V DC Input
Battery:6800 mAh Li-Ion Battery
Battery Life:10 hours
Operation System:Linux
Data Storage:16GB internal storage
Start-up Time:3 Seconds
Positioning Output Frequency:1Hz - 20Hz
Signal Tracking:
GPS (L1 C/A, L2 C/A, L2P, L5)
GLONASS (L1 C/A, L1P, L2 C/A, L2P)
BeiDou (B1, B2, B3)
Galileo:Reserved
Bands: 116 Bands

Titan TTS2




Hubungi Kami




Spesifikasi Total Station TITAN TTS2 :

Resolution:320x240 pixels
Weight:≤5.5kg
Battery:7.4VDC/3000mAH
Operation:Optimally 18 hours
Minimum Readout:5″
Method:Absolute encoding
Accuracy:2″
Compensator System:Dual-axis
Compensator Range:±3′
Compensator setting accuracy:1″

Topcon GM 101




Hubungi Kami




Spesifikasi Total Station Topcon GM 101 :

1.000 m rentang non-prisma
6.000 m rentang prisma
Akurasi sudut “terbaik di kelasnya” 1.
Hingga 32 GB penyimpanan
IP66 tahan air / debu-bukti
Kompatibel dengan thumb drive standar industri
Daya tahan baterai 21 jam dalam mode normal
Angle Measurement
Min. Resolution/Accuracy
GM-101 : 0.5”/1”
IACS : Standard on 1” and 2” models
Compensation : Dual-axis compensator
Distance Measurement
Prism EDM Range : 6,000 m
Prism EDM Accuracy : 1,5 mm + 2 ppm
Non-Prism Range : 1,000 m
Non-Prism Accuracy : 2 mm + 2 ppm | (0,3 – 200 m)
Measuring Time Fine: 0,9 sec | Rapid: 0,6 sec | Tracking: 0,4 sec
Communications
LongLinkTM is not supported
Bluetooth® Class 1,5/10 m
USB 2.0 Slot (Host)
RS-232C Serial
General
Display Single Backlit LCD | (Dual display optional)
Battery Operation : Up to 28 hours
Dust/Water Rating : IP66
Wireless Connection : Bluetooth® Class 1.5
Operating Temp: -20oC to 60oC | Special Arctic version available : (-35 to 50oC) | Laser : plummet standart. | Optional optical plummet available in some global location


Topcon GM 55

























Hubungi Kami




Spesifikasi Total Station Topcon GM 55 :

Total Station Topcon GM 55 ( Pengganti Topcon ES 65 )
1 Display ( 1 Layar )
Laser Reflectorless 500 Meter non-prism range
4,000 m prism range
Akurasi 5 Detik
Up to 50,000 point Built In Memory
Waterproof/dust-proof IP66
Environmentally protected
Compatible with industry standard thumb drives
work with one battery up to 14 hours



Gowin TKS 202N

























Hubungi Kami



Spesifikasi Total Station Gowin TKS 202 :

The Gowin total station provides an accurate, low cost measuring solution featuring:
* 2" angle accuracy provides 1/16th of an inch accuracy at 1,000ft.
* Dual keyboards with and expanded numeric keypad for faster data input.
* Accurately measure up to 2,000m with a single prism.
* Internal data storage for up to 24,000 points.
* Single axis compensator with 3' compensating range.
* IP54 environmental protection rating.

Sokkia B30




Hubungi Kami



Spesifikasi Sokkia B30 :

Magnification 28x
Hole objective lens 36mm ( 1.4in . )
Minimum focus 0.2m ( 7.9in . )
From the end of the telescope 0.3m ( 1.0ft . )
From the center of the instrument Accuracy without micrometer 1.5mm ( 0.06in . )

Sokkia B20













Hubungi Kami



Spesifikasi Sokkia B20 :

Length 215mm ( 8.46in.)
Magnification 32x
Objective aperture 42mm ( 1.65in.)
Resolving power 3"
Field of View
( at 100m/ 328ft.) 1 20'
( 2.3m / 7.5ft.)
 Minimum focus 0.2m ( 7.9in.)

Topcon AT-B3













Hubungi Kami



Spesifikasi Sokkia AT-B3 :

28x Magnifications
Rapid, Accurate, and Stable Automatic Compensation
Ultra-Short 20cm (7.9 in.) Focusing
All-Weather Dependability
Clampless, Endless Fine Horizontal Adjustments
Resolving Power : 3 ,5 “

Topcon HiPer V




Hubungi Kami



Spesifikasi GPS Topcon HiPer V :


PHYSICAL AND ENVIRONMENTAL
Enclosure
Magnesium alloy housing
Dimensions
7.24” D x 3.74“ H
(184mm D x 95mm H)
POWER AND ELECTRICAL
Standard Battery
Detachable, Li-ion rechargeable battery, 7.2V, 4.3Ah
Operation Time*

>7.5 hours in static mode w/Bluetooth® connection

Garmin 62s













Hubungi Kami



Spesifikasi GPS Garmin 62s :


Physical dimensions2.4" x 6.3" x 1.4" (6.1 x 16.0 x 3.6 cm)
Display size, WxH1.43" x 2.15" (3.6 x 5.5 cm); 2.6" diag (6.6 cm)
Display resolution, WxH160 x 240 pixels
Display typetransflective, 65-K color
TFTWeight7.9 oz (223 g) with batteriesBattery2 AA batteries (not included)
NiMH or Lithium recommendedBattery life20 hours
IPX7High-sensitivity receiver
Interfacehigh-speed USB and NMEA 0183
compatibleBarometric

altimeterElectronic compassYes (tilt-compensated 3-axis

Garmin etrex 10













Hubungi Kami



Spesifikasi GPS Garmin Etrex 10 :


Physical dimensions
2.1" x 4.0" x 1.3" (5.4 x 10.3 x 3.3 cm)
Display size, WxH
1.4" x 1.7" (3.6 x 4.3 cm); 2.2" diag (5.6 cm)
Display resolution, WxH
128 x 160 pixels
Display type
transflective, monochrome
Weight
5 oz (141.7 g) with batteries
Battery
2 AA batteries (not included); NiMH or Lithium recommended
Battery life
25 hours
IPX7
High-sensitivity receiver
Interface

USB


GPS Garmin 78s













Hubungi Kami



Spesifikasi GPS Garmin 78s :


Physical dimensions
2.6" x 6.0" x 1.2" (6.6 x 15.2 x 3.0 cm)
Display size, WxH
1.43" x 2.15" (3.6 x 5.5 cm); 2.6"
Display resolution, WxH
160 x 240 pixels
Battery
2 AA batteries (not included); NiMH or Lithium recommended
Battery life
20 hours
IPX7
Electronic compass
Yes (tilt-compensated 3-axis)
Unit-to-unit transfer (shares data wirelessly with similar units)

Floats

SOKKIA DT 740













READY STOCK



Spesifikasi Sokkia DT 740 :


TELESCOPE
Length 149mm (5.9in)
Objective aperture 45mm (1.8in)
Magnification 30x
Resolving power 2.5"
Image/Field of view Erect 1o30' (26m/1,000m)
Minimum focus 0.9m (3.0ft)
Stadia Multiplication constant: 100
Additive constant : 0
Reticle illumination Yes
ANGLE MEASUREMENT
Method Absolute rotary encoder scanning
Detecting Horizontal : Diametrical
Vertical : Single
Display resolutions 5"/10"
1/2mgon
Accuracy 7"
Circle diameter 71mm (2.8in)
Automatic compensation range     -
GENERAL
Control panel layout On both faces
Display LCD, 7 digits x 2 lines, backlight
Interface -
Optical plummet Magnification : 3x
Field of view 3o
Min. Focus 0.5m (1.64ft)
Sensitivity of levels Plate level : 40"/2mm
Circular level : 10'/2mm
Tribrach Detachable
Operating temperature -20 to + 50oC (-4 to +122oF)
Dust and water protection IP66 (IEC60529 : 2001)
Size (w/handle) W188 x D149 x H313 mm
Weight (w/batteries) 4.1kg (9.0lbs)
POWER SUPPLY
Battery LR6 / AA Batteries x 4
Operating time
w/alkaline batteries
at 20oC (68oF)
150 hours



SOKKIA B40













Hubungi Kami



SPESIFIKASI WATERPASS SOKKIA B40 / AUTOMATIC LEVEL

26X Automatic Level
1/16-in.(1.5mm) at 200-ft.(60m) leveling accuracy
Up to 300-ft.(90m)
Horizontal circle
Lock-out device
Large aperture
Wire-hung magnetically dampened compensator - within ± 15 arc minutes of level
Built-in sighting scope and bubble vial
Soft control knobs
Horizontal circle
Infinite tangent screw


TRIPOD SURVEY ( Topcon - Sokkia - Nikon )


  Hubungi Kami









TRIPOD SURVEY ( Topcon - Sokkia - Nikon )

Definisi Tripod berguna sebagai penyangga alat ukur / surveying yang terdiri atas tiga buah kaki berbentuk batang dengan bahan alumunium atau bahan lainnya. Disini kami Global Survey menyediakan macam - macam perlengkapan survey . Bilamana anda berminat bisa hubungi kontak kami atau datang langsung ke kantor kami.
